Brand Name : LEADYO
Model Number : LP48V105
Certification : UN38.3, CE,MSDS,UKCA
Place of Origin : China
MOQ : 1pcs
Price : Negotiable
Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram,Online
Supply Ability : 60Mwh
Delivery Time : 15-45 Days
Packaging Details : UN3480 Standard Export
Type : lifepo4 battery pack,lithium ion battery ,lithium Iron phosphate battery,deep cycle batteries
Voltage : 48V 51.2V
Capacity : 50Ah
Weight : 25kg
Dimension((L*W*H) : L400*W315*T180mm
Case : Metal Case
Charging Voltage : 57.6V
High Light : 48V lifepo4 golf cart battery
Cycle : 5000+
Discharge : 2.5C continuous
Charge : 0.C-1C
Commnication : Bluetooth , LCD ,RS232 ,RS485 OR CANBUS
48V 50Ah 51.2V LiFePO4 Golf Cart Battery, 150A BMS, 5000+ Cycles Lithium Battery,
Lithium iron phosphate (LiFePO4) battery packs have gained popularity as a preferred choice for golf carts due to several compelling reasons. Firstly, LiFePO4 batteries offer a higher energy density compared to traditional lead-acid batteries commonly used in golf carts. This means that they can store more energy in a smaller and lighter package, allowing the golf cart to travel longer distances on a single charge.
Nominal voltage | (48V)51.2V | (48V)51.2V | (48V)51.2V |
Capacity (Ah) | 50Ah | 105Ah | 150Ah |
Battery Energy | 2560Wh | 5376Wh | 7680Wh |
Self-discharge | ≤3% per month at 25 | ≤3% per month at 25 | ≤3% per month at 25 |
Cycle life | >4000 cycles | >4000 cycles | >4000 cycles |
Charge Mode | CC/CV | CC/CV | CC/CV |
Charge Cut-off Voltage | 58.4V | 58.4V | 58.4V |
Recommended Charge Current | 10A-20A | 10A-50A | 30A-75A |
Max. Continuous Charge Current | 50A | 100A | 150A |
Max. Continuous Discharge Current | 150A | 250A | 250A |
Max. Pulse Current | 170A 120S | 260A 120S | 300A 120S |
250A/20S | 520A/20S | 520A/20S | |
Discharge Cut-off Voltage | 35.2V | 35.2V | 35.2V |
Communication mode | UART/RS485/CAN | UART/RS485/CAN | UART/RS485/CAN |
Storage temperature | 0~45℃ | 0~45℃ | 0~45℃ |
Working Environment | 0℃~+55℃(Charge) | 0℃~+55℃(Charge) | 0℃~+55℃(Charge) |
-20℃~+65℃(Discharge) | -20℃~+65℃(Discharge) | -20℃~+65℃(Discharge) | |
Housing Material | Metal case | Metal case | Metal case |
Bluetooth 5.0 | Yes | Yes | Yes |
Display Screen | Optional | Optional | Yes |
OEM & ODM | Optional | Optional | Optional |
Dimension (mm) | 400*315*180 | 460*334*247 | 500*300*230 |
Weight | 55.00lbs.(25kg) | 99.20lbs.(45kg) | 163.13lbs.(60kg) |
FAQ
1. Do you provide OEM/ODM service ?
Yes ,can customized your brand battery
2.Do you have MOQ requests?
NO ,We don't have.
3.When you delivery order?
Normally 7-15 days for samples order , it can be negotiated based on exact order quantity and schedule.
5.May i get the golf cart lifepo4 battery with different capacity and voltage ?
Yes,please contact us.
6.How to get a quote?
Please contact us,leadyo@leadyo-battery.com
![]() |
